The Vantage 700 Series includes the same specifications as the 500 Series, but with a deeper top carve, optional coil tap, and standard Licensed Floyd Rose tremolos.

718

96 718

1996 718GJT TBU

718BFT features KKT-1 tremolo and Black hardware.

718GJT features KKT-2 tremolo and Gold hardware.

718BDT features KKT-3 tremolo and Black hardware.

718GDT features KKT-3 tremolo and Gold hardware.

718(XXX)-1 features coil tap mini-switch.

  • 1991-1996

Body:

  • Contoured, solid Alder body w/ arched top
  • Spoon cut (Single)
  • Angled heel
  • Belly carve

Neck:

  • Bolt-on Rock Maple neck with scarf joint
  • Rosewood fretboard with dot inlays
  • Inlays offset after 9th fret
  • Silk-screened Vantage logo
  • Gibson style nut
  • 24 frets
  • 25.5" scale

Electronics:

  • Two AlNiCo single coils, one humbucker
  • Molded plastic pickup covers
  • Coil tap mini-switch (-1)
  • 5-way switch
  • 3 on/off mini-switches (Early models)
  • 1 Vol, 2 Tone
KKT2

KKT-2 tremolo

Hardware:

  • Black hardware (B)
  • Gold hardware (G)
  • Schaller style tuners
  • Wide fish shaped truss rod cover
  • Metal knobs
  • "KKT-1" Licensed Floyd Rose 2-point tremolo (FT)
  • "KKT-2" Licensed Floyd Rose 2-point tremolo (JT)
  • "KKT-3" Licensed Floyd Rose locking 2-point tremolo (DT)
  • Locking nut (FT, JT)
  • Zero fret locking nut (DT)

Finishes:

  • Translucent Black (TBK)
  • Translucent Red (TR)
  • Translucent Burgundy (TBU)
  • Marble Stone Metallic Blue (MSMBL)
  • Black Fishnet (BFN)

720BDT

720BDT-1 features coil tap mini-switch.
Angled heel

Angled Heel

Body:

  • Contoured, solid Alder body w/ arched top
  • Spoon cut (Single)
  • Angled heel
  • Belly carve

Neck:

  • Bolt-on Rock Maple neck with scarf joint
  • Rosewood fretboard with dot inlays
  • Inlays offset after 9th fret
  • Silk-screened Vantage logo
  • 24 frets
  • 25.5" scale

Electronics:

  • Two AlNiCo humbuckers, one single coil
  • Molded plastic pickup covers
  • Coil tap Mini-switch (-1)
  • 5-way switch
  • 3 on/off mini-switches (Early models)
  • 1 Vol, 2 Tone
KKT3

Hardware:

  • Black hardware (B)
  • Schaller style tuners
  • Wide fish shaped truss rod cover
  • Metal knobs
  • "KKT-3" Licensed Floyd Rose locking 2-point tremolo (DT)
  • Zero fret locking nut (DT)

Finishes:

  • Marble Stone Charcoal Fire Dark Sunburst (MSCFD)

728GDT-1

96 728GDT

1996 728GDT AVS

Body:

  • Contoured, solid Alder body w/ arched top
  • "Tiger Tail" flame Maple veneer
  • Spoon cut (Double)
  • Beveled heel
  • Belly carve

Neck:

  • Set-in Rock Maple neck with scarf joint
  • Rosewood fretboard with dot inlays
  • Inlays offset after 9th fret
  • Cream neck binding and purfling
  • Silk-screened Vantage logo
  • "Tiger Tail" headstock veneer
  • 24 frets
  • 25.5" scale

Binding:

  • Double-ply neck

Electronics:

  • Two alNico Vantage noise-cancelling single coils, one Vantage humbucker
  • Molded plastic pickup covers
  • Coil tap mini-switch
  • 5-way switch
  • 1 Vol, 2 Tone ( neck and middle/bridge)
Beveled heel

Beveled Heel

Hardware:

  • Gold hardware (G)
  • Schaller style tuners
  • Wide fish shaped truss rod cover
  • Metal knobs
  • "KKT-3" Licensed Floyd Rose locking 2-point tremolo (DT)
  • Zero fret locking nut (DT)

Finishes:

  • Translucent Red (TR)
  • Antique Violin Sunburst (AV, AVS)
